Provides compact high-ampere busing with 3/8" terminal studs

  • Insert molded stainless steel studs eliminate need for securing nut and allow high torquing for excellent electrical contact
  • Raised bus provides easy access to multiple wires on a single screw or stud
  • UL 94-V0 rated base material resists high heat
  • Recessed mounting holes eliminate accidental shorts to aluminum and steel mounting surfaces
  • Base Material - Reinforced Polycarbonate
  • Bus Material - Tin-Plated Copper CDA 110 / UNS 11000
  • CE Certified
Maximum Voltage 300V AC
48V DC
Number of Terminal Studs 8
Terminal Type 3/8"-16 Stud
Terminal Stud Torque 140 in-lb (15.82 Nm)
Continuous Rating 545A AC
600A DC
Base Material UL 94-V0 Rated, Glass Reinforced Thermoplastics
Bus Material Tin-Plated Copper CDA 110/ UNS11000
Screw Terminal Torque 15 in-lb (1.69 Nm)
Weight 2.75lb (1.25 kg)



SKU BSS2107B
Barcode # 2107B-BSS
Brand Blue Sea Systems
Shipping Weight 1.1800kg
Shipping Width 0.050m
Shipping Height 0.055m
Shipping Length 0.290m
Shipping Cubic 0.000797500m3
