Trina Vertex S+ 475W - 1762 x 1134 x 30mm - 21.0KG

N-type i-TOPCon Ultra DUAL GLASS MONOCRYSTALLINE MODULE

Built from local installer feedback, the Vertex S+ Low-Voltage Module combines lower open-circuit voltage (Voc) with the proven performance and reliability of our Vertex S+ series.
This optimized design supports more modules per string, reducing BOS costs, increasing system flexibility, and boosting long-term returns for APAC homes.

The 1.6+1.6mm dual-glass structure enhances fire safety (class A+C) and long-term reliability, outperforming conventional backsheet modules for decades of safe and powerful operation.

High Reliability
Built with dual-glass design for long-term performance in APAC’s harsh environments

Higher Power Generation
Up to 40W higher power output and 1%+ higher solar cell efficiency

High Customer Value
  • Suitable for residential and C&I rooftop
  • Perfect size and low weight for handling and installation
  • Compatible with mainstream inverters and diverse mounting systems
  • Mechanical test load up to 5400 Pa front side and 4000 Pa back side
  • Certified lifetime carbon footprint assessmen

High reliability with light double glass

  • Less prone to micro-cracks and scratches on the back side
  • Fire Safety Class rating C, Safety Class II
  • Up to 25 years product warranty and 30 years power warranty

High power up to 475W

  • Up to 23.8% module efficiency, on 210 innovative platform
  • Patented i-TOPCon technology with continuous efficiency improvement, including contact resistance reduction, rear reflection enhancement and edge quality repairment

High energy yield

  • Excellent low irradiation performance, validated by 3rd party
  • Lower temperature efficient (-0.29%/°C) and lower working temperature
RATED VOLTAGE: 18V
CELL TYPE: Monocrystalline silicon 182 mm
RATED POWER: 475W
OPEN CIRCUIT (VOC): 37.00V
SHORT CIRCUIT CURRENT (ISC): 15.97A
PEAK POWER VOLTAGE (VMP): 31.65V
PEAK POWER CURRENT (IMP): 15.01A
PANEL DIMENSIONS (MM): 1762 x 1134 x 30mm
GROSS WEIGHT (KG): 21.0KG
SKU SPT475
Brand Trina
Shipping Weight 21.0000kg
Shipping Width 1.200m
Shipping Height 0.150m
Shipping Length 1.800m
Shipping Cubic 0.324000000m3
