• The fuse system recommended by most inverter manufacturers for high speed response to short circuits
  • Clear insulating cover, satisfies ABYC/USCG requirements
  • For use on systems up to 160 Volts DC
  • Large 3/8"-16 stud terminals accept ring terminals for wire up to 4/0 AWG
  • Large heat dissipating tin-plated copper mounting blocks
  • Fuse sold separately
Ignition Protected (1) No
Maximum Voltage 160V DC
Maximum Amperage (2) 400A (3)
Fuse Mounting Blocks Tin-Plated Copper
Maximum Cable Size 4/0 AWG
Maximum Torque 190 in-lb (21.47 Nm)
Mounting Holes Accept 1/4 (M6) Screw
Terminal Stud Size 3/8" - 16 (M10)
Weight 1.10lb (0.5 kg)
  1. Devices, which operate in a potentially explosive environment, must be ignition protected. This would include engine rooms with gasoline engines. There are a very specific set of tests which a device must pass to claim ignition protection. They include operating safely in an explosve mixture of propane and air.
  2. Maximum Amperages are dependent on the correct size fuse and cable being used for a given application.
  3. BEST PRACTICE: Limit the amount of current in the circuit to 80% of the fuse rating.
SKU 632085055028
Barcode # 5502-BSS
Brand Blue Sea Systems
Shipping Weight 0.5000kg
Shipping Width 0.050m
Shipping Height 0.060m
Shipping Length 0.180m
Shipping Cubic 0.000540000m3
